Vortex Mixer

The Pinnacle laboratory equipment is an exceptional solution for all your laboratory mixing needs. It offers a host of features that enhance its functionality and usability. Here are the key features presented in a reader-friendly, bullet-point format:

  • Wide Speed Range: The equipment offers an impressive speed range of 0-3000rpm, ensuring optimal mixing capabilities.

  • Fast Mixing: It can thoroughly mix full 50ml containers in just 3 seconds, enhancing efficiency.

  • Multiple Modes: It features touch mode, timer mode, and continuous mode, providing varied operational options.

  • Brushless DC Motor: The equipment is equipped with a brushless DC motor, which ensures durability and long-term use.

  • Sturdy Base: The base is made of robust iron/aluminum casting, providing stability during operation.

  • Compact Design: The compact design makes it easy to use and store, making it a perfect fit for any laboratory.

  • Low Operation Voltage: The equipment operates at a low voltage of 12V, ensuring safety and energy efficiency.

  • Dynamic Balance Design: The perfect dynamic balance design eliminates any movement in mixing, ensuring precision in results.

  • Compatibility: It is compatible with multiple voltage options and various interchangeable attachments, making it versatile and adaptable to different laboratory needs.

The Pinnacle laboratory equipment is a must-have for any laboratory looking to improve efficiency and precision in mixing processes. Its robust features and exceptional performance make it a standout choice in the market.

NOTE: Institutional & Contract Discounts Available - Enquire For Pricing

Additional information

Operation Mode

Continuous / touch operation

Type of Movement

Orbital

Orbital Diameter

6mm

Speed Range

0-3000rpm

Speed Display

Scale

Permissible Ambient Temperature

5-40°C

Permissible Relative Humidity

80%

Protection class accordin to DIN EN 60529

IP21

Voltage [VAC]

200-240 / 115 /100V compatible

Power [W]

36

Frequency [Hz]

50/60

Motor Rating Input [W]

30

Motor rating output [W]

15

Dimensions (W x H x D)

107x146x166mm

Weight [kg]:

3

  • Wide speed range of 0-3000rpm
  • Orbital diameter of 6mm
  • Touch mode, timer mode and continuous mode are available
  • Brushless DC motor and sturdy iron/aluminum casting base
  • Low operation voltage(12V) for full protection
  • Excellent mixing capability can make full 50ml containers mix within 3 seconds
  • Perfect dynamic balance design can eliminate any movement in mixing
  • Various applications with different interchangeable attachments
  • Power supply is CE, cULus, CCC, SAA and FCC certified
